Peaktronics Actuator Test Equipment for Automation


If you have questions or need technical information about any of the actuator test equipment on this page, please call us direct at (248) 542-5640. Our experienced engineers can help find solutions to your automation challenges!

Print Page

Actuator Test Equipment: Automation Solutions | Peaktronics - clc

Actuator Test Equipment: Automation Solutions | Peaktronics - spc

Actuator Test Equipment: Automation Solutions | Peaktronics - apc

Model Description List
CLC-100 Actuator Test Equipment: Automation Solutions | Peaktronics - pdf-icon

Current Loop Calibrator

4-20mA generator for calibrating all 117VAC AMC-100/101, LRC-101, and SVC-100 units

$337.50
SPC-100 Actuator Test Equipment: Automation Solutions | Peaktronics - pdf-icon

Switch/Pot Calibrator

Open-close motor switch used to calibrate actuator limit switches and binding posts to monitor feedback pot resistance. Works with all 117VAC AMC-100/101, LRC-101, and SVC-100 units.

$250.00
APC-100 Actuator Test Equipment: Automation Solutions | Peaktronics - pdf-icon

AC Positioning Calibrator

Bench style calibrator with feedback pot meter, 4-20mA generator, and 4-20mA digital input/feedback meter for calibrating 117VAC positioners (VCM Modules adapt unit for other voltages).

$1,250.00
VCM-100

Voltage Converter Module (24VAC)

Plugs into APC-100 to convert 117VAC power to 24VAC for calibrating 24VAC actuators.

$375.00
VCM-101

Voltage Converter Module (234VAC)

Plugs into APC-100 to convert 117VAC power to 234VAC for calibrating 234VAC actuators.

$375.00
VCM-102

Voltage Converter Module (12/24VDC)

Plugs into APC-100 to convert 117VAC power to 12/24VDC for calibrating 12/24VDC actuators.

$812.50
CIC-100

Calibrator Interface Cable

Interfaces APC-100 calibrator to FTE-100/101 enclosures.

$125.00
